美国CTI6230HB，CTI6230HC系列扫描振镜出售，CTI6240H振镜，剑桥6200系列振镜代理商，CTI振镜维修159-901-990-65顾先生。CTI振镜体积小，速度快，精度高，质量非常稳定，被广泛运用于激光打标，振镜焊接，舞台演示，水晶内雕，三维动态聚焦，医疗激光等领域。
        美国剑桥公司全名CambridgeTechnologyINC，简称CTI，成立于1978年作为一个供应商，在生物医学研究领域的仪器仪表产品的开发商。当时他们建立技术创新，高品质的制造和客户承诺CTI的标准。在努力实现的精度和准确度的最高级别的产品，剑桥高速奠定了闭环振技术，现在是剑桥的独家产品重点的基础。
剑桥科技公司成立，作为一个供应商，在生物医学研究领域的仪器仪表产品的开发商。在1978年，当时我们建立技术创新，高品质的制造和客户承诺我们的标准。在努力实现的最高水平准确度可以达到我们的产品，我们奠定了闭环振技术，现在是我们的独家产品重点的基础。
       通过我们不断致力于研发和创新，我们已经开发了振镜位置检测器的设计和关键技术专利的进展。这些创新使我们能够引进具有提高了精度，速度，性能和可靠性棒产品在科学和OEM光学扫描解决方案。我们的工程师与我们的客户群开发产品的配置，易于使用和集成端无缝集成到他们的具体应用。我们的配套产品种类齐全，致力于客户服务和持续的产品的研究方提供优质，创新，并相信我们的客户期望从剑桥的技术保证。
       从第一剑桥科技提供的产品 - 所有的方式达到我们目前的产品线 - 。我们的承诺，这些已在我们的振技术的世界领先的标准，我们感到自豪，我们是保持建立在价值观念 - 这些允许值使我们的客户一次又一次的成功。
       2009年1月。市场和技术在光学扫描已加入为您带来的光学扫描解决方案是最好的。从应用程序的特定组件扫描头的领导人，我们的综合公司为您提供无与伦比的扫描技术和最广泛的模拟和数字组合扫描解决方案
Model 6231HC Moving Magnet Closed Loop Galvanometer Based Optical Scanner（CTI6231HC系列扫描振镜）


The 6231H supports apertures of 8mm, 10mm, 12mm, and 15mm. It is shown here with the C connector and a 10mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degrees. Consult manual for complete operating instructions.

Mechanical
Rated Angular Excursion: 40°
Rotor Inertia: 0.82 gm cm2 , +/-10%
Torque Constant: 1.11x105 dyne cm/amp, +/-10%
Maximum Rotor Temperature: 110° C
Thermal Resistance (Rotor to Case): 1° C/Watt, Max

Electrical/Drive Mechanism
Coil Resistance: 1.27 Ohms, +/-10%
Coil Inductance: 176 µH, +/-10%
Back EMF Voltage: 195 µV/degree/sec, +/-10%
RMS Current: 5.8 Amperes at Tcase of 50° C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 250 µs, with balanced load of 0.3 gm*cm2

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/° C, Maximum
Zero Drift: 15 µrad/° C, Maximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%

Model 6230H Moving Magnet Closed Loop Galvanometer Based Optical Scanner（CTI6230H系列扫描振镜）


The 6230H galvanometer can be designed and optimized for speed, size, cost and accuracy with typical beam diameters of 8mm, 10mm, 12mm, and 15mm. It is shown here with a 10mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degrees. Consult manual for complete operating instructions.

Mechanical Specifications
Rated Angular Excursion: 40°
Rotor Inertia: 0.97 gm cm2, +/-10%
Torque Constant: 1.31x105 dyne cm/amp, +/-10%

Maximum Rotor Temperature: 110°C Thermal
Resistance (Rotor to Case): 0.80°C/Watt, Max

Electrical Specifications/Drive Mechanism
Coil Resistance: 1.07 Ohms, +/-10%
Coil Inductance: 173 uH, +/-10%
Back EMF Voltage: 229 µV/degree/sec, +/-10%
RMS Current: 7.1 Amperes at Tcase of 50°C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 250 µs, with 8mm Y Mirror, settled to 99% 250 µs, with 10mm Y mirror, settled to 99%

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/°C, Maximum
Zero Drift: 15 µrad/°C, Maximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%

Model 6240H Moving Magnet Closed Loop Galvanometer Based Optical Scanner（CTI6240H系列扫描振镜）


The 6240H galvanometer can be designed and optimized for speed, size, cost and accuracy with typical beam diameters of 12mm, 15mm, 20mm, 25mm, and 30mm. It is shown here with a 12mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degree. Consult manual for complete operating instructions.

Mechanical Specifications
Rated Angular Excursion: 40°
Rotor Inertia: 2.4 gm cm2, +/-10%
Torque Constant: 2.0x105 dyne cm/amp, +/-10%
Maximum Coil Temperature: 110°C
Thermal Resistance (Coil to Case): 0.62°C/Watt, Max

Electrical Specifications/Drive Mechanism
Coil Resistance: 1.03 Ohms, +/-10%
Coil Inductance: 350µH, +/-10%
Back EMF Voltage: 346 µV/degree/sec, +/-10%
RMS Current: 8.2 Amperes at Tcase of 50°C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 300 µs, with 12mm Y mirror, settled to 99%#p#分页标题#e#
350µs, with 15mm Y mirror, settled to 99%
650 µs, with 20mm Y mirror, settled to 99%

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/°C, Maximum
Zero Drift: 15 µrad/°C, aximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%
本公司直接代理销售美国剑桥（CambridgeTechnologyINC）的各型号扫描振镜并提供维修服务
